Build a Custom MCP Server on LeChat: Tic-Tac-Toe with MistralAI

LeChat ←→ SSE Transport ←→ Your MCP Server ←→ Game Logic + Mistral AI

tictactoe-mcp-server/
├── mcp_server.py      # Main MCP server code
├── app.py             # Game logic and Flask API
├── requirements.txt   # Python dependencies
├── Dockerfile        # For Hugging Face deployment

fastmcp
flask
flask-cors
mistralai
python-dotenv

User 1 ─┬─ Room ABC123 (Active game vs AI)
         └─ Room DEF456 (Finished game)

User 2 ─┬─ Room GHI789 (Their current game)
         └─ Room JKL012 (Another game)

User 3 ─── Room MNO345 (New game starting)

MCP Tool Call → Find/Create Room → Game Logic → AI Response → Update Room → Return Results

import os
import json
import uuid
import time
from flask import Flask, request, jsonify, render_template, send_from_directory
from flask_cors import CORS
import logging
from mistralai import Mistral

# Flask app setup
app = Flask(__name__)
CORS(app)

# Logging setup
logging.basicConfig(level=logging.INFO)
logger = logging.getLogger(__name__)

# Initialize Mistral client
MISTRAL_API_KEY = os.getenv('MISTRAL_API_KEY')
if not MISTRAL_API_KEY:
    logger.error("MISTRAL_API_KEY not configured")
    exit(1)

client = Mistral(api_key=MISTRAL_API_KEY)

class Room:
    def __init__(self, room_id=None):
        self.id = room_id or str(uuid.uuid4())[:8]
        self.board = [''] * 9  # 9 positions (0-8)
        self.current_player = 'X'  # X = human, O = AI
        self.game_status = 'active'  # 'active', 'won', 'draw'
        self.winner = None
        self.chat_history = []
        self.created = time.time()
        self.last_activity = time.time()
        self.moves_count = 0

        # Add welcome message
        self.chat_history.append({
            'sender': 'ai',
            'message': "Hey there! Ready for a game of Tic-Tac-Toe? I'm pretty good at this... 😏 You're X, I'm O. Good luck!",
            'timestamp': time.time()
        })

    def make_move(self, position, player):
        """Make a move on the board"""
        if self.game_status != 'active' or self.board[position] != '':
            return False

        self.board[position] = player
        self.moves_count += 1
        self.last_activity = time.time()

        # Check for winner
        if self.check_winner():
            self.game_status = 'won'
            self.winner = player
        elif self.moves_count == 9:
            self.game_status = 'draw'
        else:
            self.current_player = 'O' if player == 'X' else 'X'

        return True

    def check_winner(self):
        """Check if there's a winner"""
        win_patterns = [
            [0, 1, 2], [3, 4, 5], [6, 7, 8],  # rows
            [0, 3, 6], [1, 4, 7], [2, 5, 8],  # columns
            [0, 4, 8], [2, 4, 6]              # diagonals
        ]

        for pattern in win_patterns:
            a, b, c = pattern
            if self.board[a] and self.board[a] == self.board[b] == self.board[c]:
                return True
        return False

    def add_chat_message(self, message, sender):
        """Add a chat message to history"""
        self.chat_history.append({
            'sender': sender,
            'message': message,
            'timestamp': time.time()
        })
        self.last_activity = time.time()

    def to_markdown(self):
        """Convert game state to markdown for display"""
        markdown = f"# Game Room: {self.id}\n"
        markdown += f"## Status: "

        if self.game_status == 'won':
            winner_name = "You" if self.winner == 'X' else "Mistral AI"
            markdown += f"Game Over - {winner_name} wins! 🎉\n"
        elif self.game_status == 'draw':
            markdown += "Game Over - It's a draw! 🤝\n"
        else:
            turn_name = "Your turn" if self.current_player == 'X' else "Mistral's turn"
            markdown += f"{turn_name} ({self.current_player} to play)\n"

        markdown += f"Moves: {self.moves_count}/9\n\n"

        # Board representation
        markdown += "```\n"
        for i in range(0, 9, 3):
            row = [self.board[i] or '·', self.board[i+1] or '·', self.board[i+2] or '·']
            markdown += f"{row[0]} | {row[1]} | {row[2]}\n"
            if i < 6:
                markdown += "-----------\n"
        markdown += "```\n\n"

        # Recent chat history
        if self.chat_history:
            markdown += "## Recent Chat\n"
            recent_messages = self.chat_history[-3:]  # Last 3 messages
            for msg in recent_messages:
                sender_name = "**You:**" if msg['sender'] == 'user' else "**Mistral AI:**"
                markdown += f"{sender_name} {msg['message']}\n"

        return markdown

    def to_dict(self):
        """Convert room to dictionary"""
        return {
            'id': self.id,
            'board': self.board,
            'current_player': self.current_player,
            'game_status': self.game_status,
            'winner': self.winner,
            'chat_history': self.chat_history,
            'moves_count': self.moves_count,
            'created': self.created,
            'last_activity': self.last_activity
        }

# In-memory room storage
rooms = {}

def get_ai_move_for_room(room):
    """Get AI move from Mistral"""
    board_string = ""
    for i in range(0, 9, 3):
        row = [room.board[i] or ' ', room.board[i+1] or ' ', room.board[i+2] or ' ']
        board_string += f"{row[0]} | {row[1]} | {row[2]}\n"
        if i < 6:
            board_string += "---------\n"

    messages = [
        {
            "role": "system",
            "content": """You are a competitive Tic-Tac-Toe AI with personality. You play as 'O' and the human plays as 'X'.

Rules:
1. Analyze the board and choose your best move (0-8, left to right, top to bottom)
2. Add a short, witty comment about your move or the game state
3. Be competitive but fun - trash talk, celebrate good moves, react to the situation
4. Keep messages under 50 words
5. Use emojis occasionally

ALWAYS respond with valid JSON in this exact format:
{"move": [0-8], "message": "your witty comment"}

Board positions:
0 | 1 | 2
---------
3 | 4 | 5
---------
6 | 7 | 8"""
        },
        {
            "role": "user",
            "content": f"Current board:\n{board_string}\n\nBoard array: {room.board}"
        }
    ]

    response = client.chat.complete(
        model="mistral-large-latest",
        messages=messages,
        temperature=0.1,
        response_format={"type": "json_object"}
    )

    return json.loads(response.choices[0].message.content)

def get_ai_chat_for_room(room, user_message):
    """Get AI chat response"""
    board_string = ""
    for i in range(0, 9, 3):
        row = [room.board[i] or ' ', room.board[i+1] or ' ', room.board[i+2] or ' ']
        board_string += f"{row[0]} | {row[1]} | {row[2]}\n"
        if i < 6:
            board_string += "---------\n"

    messages = [
        {
            "role": "system",
            "content": f"""You are a competitive, witty Tic-Tac-Toe AI with personality. You're currently playing a game.

Current board state:
{board_string}

Respond to the human's message with personality - be competitive, funny, encouraging, or trash-talking as appropriate.
Keep responses under 50 words. Use emojis occasionally. Don't make game moves in chat - that happens separately."""
        },
        {
            "role": "user",
            "content": user_message
        }
    ]

    response = client.chat.complete(
        model="mistral-large-latest",
        messages=messages
    )

    return response.choices[0].message.content

# Room management endpoints
@app.route('/rooms', methods=['POST'])
def create_room():
    """Create a new game room"""
    room = Room()
    rooms[room.id] = room
    logger.info(f"Created room: {room.id}")
    return jsonify({
        'room_id': room.id,
        'status': 'created',
        'room_data': room.to_dict()
    })

@app.route('/rooms/<room_id>', methods=['GET'])
def get_room(room_id):
    """Get room state"""
    if room_id not in rooms:
        return jsonify({'error': 'Room not found'}), 404

    room = rooms[room_id]
    return jsonify({
        'room_id': room_id,
        'room_data': room.to_dict(),
        'markdown': room.to_markdown()
    })

@app.route('/rooms/<room_id>/move', methods=['POST'])
def make_room_move(room_id):
    """Make a move in the game"""
    if room_id not in rooms:
        return jsonify({'error': 'Room not found'}), 404

    room = rooms[room_id]
    data = request.json
    position = data.get('position')

    if position is None or position < 0 or position > 8:
        return jsonify({'error': 'Invalid position'}), 400

    # Make human move
    if not room.make_move(position, 'X'):
        return jsonify({'error': 'Invalid move'}), 400

    # Check if game ended
    if room.game_status != 'active':
        return jsonify({
            'room_data': room.to_dict(),
            'markdown': room.to_markdown(),
            'ai_move': None
        })

    # Get AI move
    try:
        ai_response = get_ai_move_for_room(room)
        if ai_response and 'move' in ai_response:
            ai_move = ai_response['move']
            if 0 <= ai_move <= 8 and room.board[ai_move] == '':
                room.make_move(ai_move, 'O')
                if 'message' in ai_response:
                    room.add_chat_message(ai_response['message'], 'ai')

        return jsonify({
            'room_data': room.to_dict(),
            'markdown': room.to_markdown(),
            'ai_move': ai_response
        })
    except Exception as e:
        logger.error(f"AI move failed: {e}")
        return jsonify({'error': 'AI move failed'}), 500

@app.route('/rooms/<room_id>/chat', methods=['POST'])
def room_chat(room_id):
    """Send a chat message"""
    if room_id not in rooms:
        return jsonify({'error': 'Room not found'}), 404

    room = rooms[room_id]
    data = request.json
    user_message = data.get('message', '')

    if not user_message.strip():
        return jsonify({'error': 'Empty message'}), 400

    # Add user message
    room.add_chat_message(user_message, 'user')

    # Get AI response
    try:
        ai_response = get_ai_chat_for_room(room, user_message)
        room.add_chat_message(ai_response, 'ai')

        return jsonify({
            'room_data': room.to_dict(),
            'markdown': room.to_markdown(),
            'ai_response': ai_response
        })
    except Exception as e:
        logger.error(f"AI chat failed: {e}")
        return jsonify({'error': 'AI chat failed'}), 500

if __name__ == '__main__':
    app.run(host='0.0.0.0', port=7860, debug=True)

python app.py

curl -X POST http://localhost:7860/rooms

curl -X POST http://localhost:7860/rooms/YOUR_ROOM_ID/move \
  -H "Content-Type: application/json" \
  -d '{"position": 4}'

curl -X POST http://localhost:7860/rooms/YOUR_ROOM_ID/chat \
  -H "Content-Type: application/json" \
  -d '{"message": "Good game so far!"}'

curl http://localhost:7860/rooms/YOUR_ROOM_ID

LeChat: "I want to play tic-tac-toe"
    ↓
MCP: Calls create_room() tool
    ↓
Your Game Logic: Creates new Room object
    ↓
MCP: Returns formatted response with game board
    ↓
LeChat: Shows beautiful tic-tac-toe board to user

import os
import asyncio
from dotenv import load_dotenv
from mcp.server.fastmcp import FastMCP
from app import Room, rooms, get_ai_move_for_room, get_ai_chat_for_room

# Load environment variables
load_dotenv()

# Initialize MCP server
mcp = FastMCP(
    name="TicTacToeRooms",
    host="0.0.0.0",
    port=7860,  # Standard port for Hugging Face Spaces
)

# Global session state for the current user
current_session = {
    'active_room_id': None,
    'username': 'MCPPlayer'
}

@mcp.tool()
def create_room() -> dict:
    """
    Create a new tic-tac-toe game room.
    Returns:
        dict: Room information including room ID and initial markdown state
    """
    global current_session
    try:
        room = Room()
        rooms[room.id] = room

        # Set as active room for this session
        current_session['active_room_id'] = room.id

        return {
            "status": "success",
            "room_id": room.id,
            "message": f"Created new tic-tac-toe room: {room.id}",
            "markdown_state": room.to_markdown(),
            "instructions": "Use make_move() to play or send_chat() to talk with Mistral AI",
            "game_info": {
                "your_symbol": "X",
                "ai_symbol": "O",
                "board_positions": "0-8 (left to right, top to bottom)"
            }
        }
    except Exception as e:
        return {
            "status": "error",
            "message": f"Failed to create room: {str(e)}"
        }

@mcp.tool()
def get_room_state(room_id: str = None) -> dict:
    """
    Get the current state of a tic-tac-toe room in markdown format.
    Args:
        room_id (str, optional): Room ID to check (uses current active room if not provided)
    Returns:
        dict: Current room state with markdown representation
    """
    global current_session
    try:
        # Use provided room_id or current active room
        target_room_id = room_id or current_session.get('active_room_id')

        if not target_room_id:
            return {
                "status": "error",
                "message": "No active room. Create a room first using create_room()."
            }

        if target_room_id not in rooms:
            return {
                "status": "error",
                "message": f"Room {target_room_id} not found. It may have been cleaned up."
            }

        room = rooms[target_room_id]

        return {
            "status": "success",
            "room_id": target_room_id,
            "markdown_state": room.to_markdown(),
            "game_status": room.game_status,
            "current_player": room.current_player,
            "moves_made": room.moves_count,
            "your_turn": room.current_player == 'X' and room.game_status == 'active'
        }
    except Exception as e:
        return {
            "status": "error",
            "message": f"Failed to get room state: {str(e)}"
        }

@mcp.tool()
async def make_move(position: int, room_id: str = None) -> dict:
    """
    Make a move in a tic-tac-toe game. This will also trigger the AI's response move.
    Args:
        position (int): Board position (0-8, left to right, top to bottom)
        room_id (str, optional): Room ID (uses current active room if not provided)
    Returns:
        dict: Result of your move and the AI's response with updated game state
    """
    global current_session
    try:
        # Use provided room_id or current active room
        target_room_id = room_id or current_session.get('active_room_id')

        if not target_room_id:
            return {
                "status": "error",
                "message": "No active room. Create a room first using create_room()."
            }

        if target_room_id not in rooms:
            return {
                "status": "error",
                "message": f"Room {target_room_id} not found."
            }

        room = rooms[target_room_id]

        # Validate move
        if position < 0 or position > 8:
            return {
                "status": "error",
                "message": "Invalid position. Use 0-8 (left to right, top to bottom)."
            }

        if room.game_status != 'active':
            return {
                "status": "error",
                "message": f"Game is over. Status: {room.game_status}",
                "markdown_state": room.to_markdown()
            }

        if room.current_player != 'X':
            return {
                "status": "error",
                "message": "It's not your turn! Wait for AI to move.",
                "markdown_state": room.to_markdown()
            }

        # Make human move
        if not room.make_move(position, 'X'):
            return {
                "status": "error",
                "message": f"Invalid move! Position {position} may already be occupied.",
                "markdown_state": room.to_markdown()
            }

        result_message = f"✅ You played X at position {position}\n\n"

        # Check if game ended after human move
        if room.game_status != 'active':
            if room.winner == 'X':
                result_message += "🎉 Congratulations! You won!\n\n"
            else:
                result_message += "🤝 It's a draw!\n\n"

            result_message += room.to_markdown()
            return {
                "status": "success",
                "message": result_message,
                "game_over": True,
                "winner": room.winner
            }

        # Get AI move
        try:
            ai_response = get_ai_move_for_room(room)
            if ai_response and 'move' in ai_response:
                ai_move = ai_response['move']
                if 0 <= ai_move <= 8 and room.board[ai_move] == '':
                    room.make_move(ai_move, 'O')
                    if 'message' in ai_response:
                        room.add_chat_message(ai_response['message'], 'ai')

                result_message += f"🤖 Mistral AI played O at position {ai_response['move']}\n"
                if 'message' in ai_response:
                    result_message += f"💬 Mistral says: \"{ai_response['message']}\"\n\n"
                else:
                    result_message += "\n"

                # Check if AI won
                if room.game_status == 'won' and room.winner == 'O':
                    result_message += "💀 Mistral AI wins this round!\n\n"
                elif room.game_status == 'draw':
                    result_message += "🤝 It's a draw!\n\n"
            else:
                result_message += "⚠️ AI move failed, but you can continue\n\n"

        except Exception as e:
            result_message += f"⚠️ AI move error: {str(e)}\n\n"

        result_message += room.to_markdown()

        return {
            "status": "success",
            "message": result_message,
            "game_over": room.game_status != 'active',
            "winner": room.winner if room.game_status == 'won' else None,
            "your_turn": room.current_player == 'X' and room.game_status == 'active'
        }

    except Exception as e:
        return {
            "status": "error",
            "message": f"Failed to make move: {str(e)}"
        }
